Arkel ARCODE HDA Highline Hardware Dongle (License Key)

The Arkel ARCODE HDA (Highline Hardware Dongle) is the physical license key required to unlock the maximum performance capabilities of the ARCODE Integrated Elevator Control Unit. Designed for high-rise and high-speed applications, this hardware module removes the standard software restrictions, enabling the system to manage up to 64 floors, speeds of 4.0 m/s, and group operations of up to 8 elevators.

Technical Specifications: ARCODE HDA

Product Description

The Arkel ARCODE HDA (1002749) is an essential component for integrating the ARCODE control system into high-performance vertical transportation projects. While the ARCODE hardware (the inverter and processor) remains consistent across different power ratings, its operational limits are defined by this hardware dongle.

Scalability and Flexibility: Without a dongle, the ARCODE system operates in “Basic” mode, limited to 1.6 m/s, 16 floors, and simplex/duplex operation. Inserting the HDA Dongle instantly transforms the unit into a powerhouse capable of managing the complex traffic logic required in skyscrapers and large-scale facilities.

Tiered Licensing Structure: Arkel offers licensing in three tiers to optimize project costs:

1. Basic (No Dongle): Low-rise, low speed.
2. MDA (Midline Dongle): Up to 2.5 m/s, 24 floors, 4-car group.
3. HDA (Highline Dongle): The premium solution for speeds up to 4.0 m/s, 64 floors, and 8-car groups.

Application Areas: The HDA is specifically engineered for:

• Skyscrapers & High-Rise Towers: Where floor counts exceed 24.
• High-Speed Lifts: For installations requiring rapid transit (up to 4 m/s).
• Complex Group Control: For banks of 5 to 8 elevators requiring sophisticated dispatching algorithms.

Frequently Asked Questions

Q1: Can I use the ARCODE system without any dongle?

Yes. Without a dongle, the ARCODE operates with a Basic License. This limits the system to a maximum speed of 1.6 m/s, a maximum of 16 floors, and a group size of only 2 elevators (Duplex),.

Q2: What is the difference between the MDA and HDA dongles?

The MDA (Midline) dongle supports up to 2.5 m/s, 24 floors, and 4 elevators in a group. The HDA (Highline) dongle is the advanced version, supporting up to 4.0 m/s, 64 floors, and 8 elevators in a group,.

Q3: Does the HDA dongle work with all ARCODE power models?

Yes. The licensing dongle is independent of the power rating. You can use the HDA dongle with any ARCODE unit, ranging from the 4B14A (14 Ampere) to the 4D75A (75 Ampere), to unlock high-speed/high-rise features,.

Q4: Is the dongle required for “Firefighter Lift” functions?

Generally, advanced features such as specific Firefighter Lift standards, Priority/VIP calls, and complex emergency scenarios are associated with the Highline (HDA) license tier. It is recommended to use the HDA for projects requiring these EN 81-72 compliant features.
