Arkel BC-D3XAW Landing Call & Indicator Unit (3x30mm White Dot-Matrix)
Modernize high-rise lifts with the Arkel BC-D3XAW Landing Indicator. Features a 3x30mm White Dot-Matrix display, alphanumeric scrolling, integrated gong, and seamless CANbus connectivity for ARCODE systems.
- High-Rise Capability: Equipped with a 3×30 mm matrix resolution, allowing for the clear display of 3-character floor numbers (0-999) and complex alphanumeric combinations, making it ideal for skyscrapers and large complexes,.
- Premium White Illumination: The “AW” designation indicates brilliant White LEDs, providing superior contrast and a contemporary look that aligns with modern architectural design trends, replacing traditional red displays.
- Dynamic Messaging: Beyond static numbers, the dot-matrix technology supports scrolling text for system status messages such as “Out of Service,” “Overload,” or “Fire Mode,” enhancing passenger communication.
- Seamless ARCODE Integration: Specifically listed as a peripheral for the ARCODE control unit, ensuring plug-and-play compatibility via the CANbus serial protocol without complex wiring looms,.
- Integrated Audio & Control: Features an on-board adjustable gong for arrival notification and tactile call buttons, all managed through a single robust PCB design.
Guaranteed Safe Checkout
The Arkel BC-D3XAW is a premium landing operating panel (LOP) interface designed primarily for the ARCODE Integrated Elevator Control System. Featuring a high-contrast 3×30 mm White Dot-Matrix LED display, this unit is engineered for high-rise buildings and luxury installations, capable of displaying 3-character floor designations (e.g., “105”, “B12”) and dynamic scrolling messages with a modern aesthetic,.
Technical Specifications: BC-D3XAW
| Specification | Detail |
|---|---|
| Model Code | BC-D3XAW |
| Display Type | Dot-Matrix LED (3 Characters) |
| Matrix Resolution | 3 x 30 mm |
| LED Color | White |
| Compatibility | Arkel ARCODE System |
| Communication | CANbus Serial Protocol |
| Audio Output | Integrated Gong (Adjustable Volume) |
| Approximate Price (EUR) | – |
Product Description
The Arkel BC-D3XAW is the aesthetic and functional choice for modern elevator installations requiring high information density at the landing. While standard displays are limited to two digits, the 3×30 mm configuration of this unit allows it to serve buildings with over 100 floors or complex subterranean levels (e.g., “B15”), providing clear navigation for passengers.
Visual Ergonomics and Technology: The shift to White LED technology offers higher contrast and legibility compared to standard red matrix displays. The unit connects directly to the ARCODE system via CANbus, which not only powers the unit but also allows for the synchronization of scrolling text messages (e.g., “Maintenance Mode”) and direction arrows, keeping passengers fully informed of the lift’s status.
Engineering for Efficiency: Designed for B2B efficiency, the BC-D3XAW reduces installation time by combining the call buttons, display, and audio buzzer into a single CANbus-addressable node. It eliminates the need for bundle wiring, requiring only a simple serial connection to the shaft cable.
Frequently Asked Questions
Q1: What is the difference between BC-D3XAW and BC-D3XAR?
The difference is the LED color. The BC-D3XAW uses White (W) LEDs for a modern, high-end look, while the BC-D3XAR uses standard Red (R) LEDs. Both have the same 3x30mm resolution and ARCODE compatibility,.
Q2: Is this unit compatible with the ARL-500 controller?
The BC series (e.g., BC-D3XAW) is listed in the catalog under ARCODE peripherals,. The equivalent model specifically listed for ARL-500 systems is the KK3X3057AW,. While hardware is similar, it is recommended to order the specific model code that matches your control system to ensure firmware compatibility.
Q3: Can this display show letters as well as numbers?
Yes. The dot-matrix technology allows for the display of alphanumeric characters (A-Z) and special symbols. This is essential for floors named “L” (Lobby), “P” (Parking), or “R” (Restaurant), as well as scrolling status text.
Q4: How is the volume of the arrival gong adjusted?
The unit features an on-board volume trimpot (potentiometer) on the PCB. Technicians can manually adjust this during commissioning to set the appropriate sound level for the landing environment.
